How to Replace the Blades on a Brush Hog

eHow may earn compensation through affiliate links in this story. Learn more about our affiliate and product review process here.

Brush hogs are extremely heavy rotary mowers that are usually attached to the rear of tractors. Because brush hogs operate in conditions that are typically much harsher than traditional lawn mowing, these machines have heavy duty blades that require annual replacement or sharpening. Most brush hogs have a simple design that makes replacing blades a simple task. Even an average user can learn to accomplish this task in just a few minutes using simple hand tools.

Advertisement

Brush hog blades require annual replacement or sharpening.

Video of the Day

Things You'll Need

  • Replacement Cutting Blades

  • Torque Wrench

  • Work Gloves

  • Hammer

  • Sae Socket Set

Step 1

Park the tractor with the brush hog attached on a flat level surface. Raise the mower deck of the brush hog using the tractor's hydraulic system, or whatever system normally raises the deck. Turn the tractor's engine off and set the parking brake. Remove the key.

Video of the Day

Step 2

Put on work gloves to protect your fingers from sharp metal tears that may have formed on the cutting blades since they were last inspected. Brush hog blades regularly from hit rocks and other debris, so blades are typically damaged. Fit a 1/2-inch SAE socket wrench onto the bolt that secures the first blade to be replaced. This bolt is called the spindle bolt. With a hammer, sharply strike the end of the socket wrench handle once so that the wrench turns the bolt in the counter clockwise direction.

Advertisement

Step 3

Unscrew the bolt and remove the concave washer, called a Belleville washer, that secures the cutting blade to the bottom of the blade spindle (the axle which the blade spins on). Be sure to hold onto the blade with one hand while removing the bolt so that the blade does not drop to the ground or hit your feet.

Advertisement

Step 4

Remove all brush hog blades using the same procedure. Replace all blades with new blades, or resharpened blades. Again, be sure to avoid sharp tears that may be on the blades. These tears are very sharp and may even penetrate your gloves.

Step 5

Attach each new blade to the appropriate spindle. Secure each 1/2-inch spindle bolt tightly with the socket wrench, making sure that the concave side of the Belleville washer is facing the blade. Torque each bolt to at least 75 foot pounds of torque using a torque wrench. Test the brush hog for normal operation.

Tip

The method of using a sharp tap of the hammer on the end of the socket wrench is designed to free the bolt from it's it's initial "bound" position. After the initial tap, regular wrench motion must be applied to remove a bolt.

Warning

Be careful that adjacent cutting blades do not hit you as you remove a blade. The blades are all connected via belts within the mower deck housing, so if one spins they all spin together.
