How to Refill a String Trimmer Spool

eHow may earn compensation through affiliate links in this story. Learn more about our affiliate and product review process here.
String trimmers are available in both gas and electric models.

A yard trimmer is a handy tool when maintaining a yard. The trimmer cuts grass and weeds in areas that a lawnmower cannot reach, such as along a fence line, around trees and against your home. Yard trimmers have a rotating head on the bottom of the shaft with nylon string protruding through it. When the head spins, the string acts as a blade to cut anything it its path. As you use the trimmer, the string breaks, requiring more to be unwound from the spool in the head. The spool must be re-wound with new string after you have used all the string in the spool.

Advertisement

Step 1

Turn off the string trimmer and then lay the trimmer down with the head facing up.

Video of the Day

Step 2

Remove the spool retainer on the bottom of the head by pushing in the tabs and then pulling the retainer off.

Advertisement

Step 3

Lift the spool off the head and remove any remaining string.

Step 4

Insert one end of the string into the string anchor hole on the upper portion of the spool and then wind the string around the spool in the direction of the arrows on the spool, often clockwise.

Advertisement

Step 5

Place the string through the string slot on the spool, allowing approximately 6 inches of string to remain outside the spool.

Step 6

Place the spool back onto the trimmer head and then press the spool retainer back into position to secure the spool.
